| Specifications | A-Series IPS Desktop |
| Maximum IP Cameras | 64 |
| Included IP Licenses | 4 |
| Pre-Loaded VMS Software | ProfessionalEnterprise (optional) |
| Include SSA | 3 Years |
| Operating System | Windows 10Ubuntu Linux 22.04 |
| RAID | Not Available |
| Maximum Storage | 24 TB |
| Maximum Hard Drives | 2 |
| Typical Video Storage Rate | 250 Mbps (Windows)300 Mbps (Linux) |
| Local Client Display Rate (1080p) | 375 FPS (Windows)720 FPS (Linux) |
| CPU | Intel Core i3Intel Core i5 (Optional)Intel Core i7 (Optional) |
| RAM | 8 GB16 GB (Optional) |
| Operating System Drive | 256 GB SSD |
| Operating System Redundancy | Not Available |
| Monitor Output | HDMI, DP, VGA3 Simultaneous |
| NIC | 1 x 2.5 Gbps, 1x 1 Gbps1 x 2.5 Gbps, 3 x 1 Gbps (Optional) |
| USB | 4x USB 2.0, 2x USB 3.0 |
| Alarm Inputs | External (USB I/O Optional) |
| Alarm Outputs | External (USB I/O Optional) |
| Audio Inputs | 2 |
| Audio Outputs | 1 |
| DVD | External (Optional) |
| Accessories | Keyboard, Mouse |
| Dimensions (H x W x D) | 5 x 15 x 11.75 in12.7 x 38.1 x 29.85 cm |
| Weight | 18.5 - 22.0 lbs8.4 - 10.0 kg |
| Regulatory | |
| Input Voltage | 120/240 VACauto-sensing |
| Power Supplies | Single |
| Power & Heat | 150 Watts/500 BTU/h (Max)110 Watts/370 BTU/h (Typical) |
| Operating Temperature | 40°F - 95°F4.5°C - 35°C |
| Warranty | 3 Years |
