N24CB33 - EOL Replacement: N43AB52 - EOL Replacement: N43CB62
Part number:
N24CB33
Price:
The 2 MP camera features an advanced 1/2.8-in. Progressive-scan STARVIS™ imager with a fixed lens. The camera offers True Wide Dynamic Range, a True Day/Night IR Cut filter, IP67 Ingress protection and operation in extreme temperatures to deliver superior images in all lighting and environmental conditions.
Features:
- 1/2.8-in. 2 MP Progressive-scan STARVIS™ CMOS Sensor
- Triple Stream Encoding
- Smart H. 265+ and H.264 Dual Codecs
- 2 MP at 60 fps
- 3.6 mm Fixed Lens
- Enhanced Power and Data Transmission Distances with ePoE
- Enhanced Starlight Technology
- True WDR (120 dB) and True Day/Night (ICR)
- Maximum IR LED Length 40 m (131 ft) with Smart IR
- ArcticPro Series Camera – Operational down to –40° C (–40° F)
- IP67 Ingress Protection
- Intelligent Video System
- Five-year Warranty (for products sold through an authorized Dahua Dealer)
Camera
| Image Sensor | 1/2.8-in. 2 MP Progressive-scan STARVIS™ CMOS |
| Effective Pixels | 1920(H) x 1080(V) |
| RAM/ROM | 256 MB/32 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto, Manual, 1/3 s to 1/100,000 s |
| Minimum Illumination | Color: 0.007 lux at F1.6 (1/3s, 30 IRE) Color: 0.06 lux at F1.6 (1/30 s, 30 IRE) 0 lux at F1.6 (IR on) |
| S/N Ratio | More than 50 dB |
| IR Distance | Distance up to 40 m (131.23 ft) |
| IR On/Off Control | Auto, Manual |
| IR LEDs | Two (2) |
Lens
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 3.6 mm |
| Maximum Aperture | F1.6 |
| Angle of View | Horizontal: 87° Vertical: 46° |
| Focus Control | Fixed |
| Close Focus Distance | 1.20 m (3.93 ft) |
